ASTM A234 WPB pipe fittings

Date: 2021-10-08

ASTM A234 WPB pipe fittings About ASTM A234 WPB pipe fittings ASTM A234 is Standard Specification for steel pipe fittings includes carbon and alloy steel material for moderate and high temperature services. It covers steel fittings of seamless and welded types. Steel Pipe fittings are applied in pressure pipelines and in pressure vessel fabrications. These fittings material consist of killed steel, forgings, bars, plates, seamless or HFW (fusion welded) pipe products, with filler metal added. What is WPB? W = WELDABLE / wrought P = RELATED TO P NUMBER OF ALLOY MATERIAL B = REFER TO MINIMUM YIELD OF MATERIAL They are available in latest revision of ASME B16.9, B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, and MSS-SP-97. Also widely used in pressure piping and in pressure vessel fabrication for service at moderate and elevated temperatures. The grades are ASTM A234 WPB, WPC, WP5, WP9, WP91, WP11, WP12 and WP22. Specifications: Standards: ANSI /ASME B16.9, B16.28, MSS-SP-43. Outer Diameter Range: 1/2” to 48” Thickness Range: SCH 10, sch 20, SCH 40, SCH STD, SCH 80, SCH XS, SCH 160, SCH XXS etc. Steel pipe fittings manufacturing types in forged, threaded, butt weld, and seamless. Chemical Composition (%) of ASTM A234 Mechanical properties of ASTM A234 A234 WPB Equivalent (1)The sum of Cu, Ni, Cr, and Mo shall not exceed 1.00%. (2)The sum of Cr and Mo shall not exceed 0.32%. (3)For each reduction of 0.01% below the specified C max., an increase of 0.06% Mn (4)above the specified max. will be permitted, up to a max. of 1.35%. (5)The max. carbon equivalent (C.E.) shall be 0.50, based on heat analysis and the (6)formula C.E.=C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15. The Difference Between A105 And A234 ASTM A234 WPB Pipe Fittings are made up of wrought carbon steel that they are very strong and can be applied in high strength requirements. The ASTM A234 WPB are heat treated and then allowed to cool rapidly. Carbon Steel Forged Fittings are pipe fittings made out of A105 Material. These are produced in annealed, normalized, normalized and tempered or quenched and tempered conditions. Post time: Oct-08-2021 Grade C Mn P S Si Cr Mo Ni Cu V Nb WPB 0.3 0.29-1.06 0.05 0.058 0.1min 0.4 0.15 0.4 0.4 0.08 0.02 WPC 0.35 0.29-1.06 0.05 0.058 0.1min 0.4 0.15 0.4 0.4 0.08 0.02 WP11 CL1 0.05-0.15 0.30-0.60 0.03 0.03 0.50-1.00 1.00-1.50 0.44-0.65 - - - - WP11 CL2/3 0.05-0.20 0.30-0.80 0.04 0.04 0.50-1.00 1.00-1.50 0.44-0.65 - - - - Tensile Requirements WPB WPC, WP11CL2 WP11CL1 WP11CL3 Tensile Strength, min, ksi[MPa] 60-85 70-95 60-85 75-100 (0.2% offset or 0.5% extension-under-load) [415-585] [485-655] [415-585] [520-690] Yield Strength, min, ksi[MPa] 32 40 30 45 Yield Strength, min, ksi[MPa] [240] [275] [205] [310] Pipe Fittings Flanges Valves Bolts & Nuts ASTM A106 Gr A ASTM A234 Gr WPA ASTM A105 ASTM A216 Gr WCB A193 Gr B7 A194 Gr 2H ASTM A106 Gr B A234 Gr WPB ASTM A105 ASTM A216 Gr WCB A193 Gr B7 A194 Gr 2H ASTM A106 Gr C ASTM A234 Gr WPC ASTM A105 ASTM A216 Gr WCB A193 Gr B7 A194 Gr 2H
