ERW Steel Pipe

Short Description:


  • Keywords(pipe type): ERW Pipe, ERW Steel Pipe, Electric Resistance Welded Pipe
  • Size: OD: 21.3mm ~ 660mm;WT: 1mm ~ 17.5mm; LENGTH: 0.5mtr ~ 22mtr (5.8/6/11.8/12 meters, SRL, DRL)
  • Standard & Grade: ASTM A53, Grade A/B/C
  • Ends : Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends
  • Delivery: Within 30 days and Depends on your order quantity
  • Payment: TT, LC , OA , D/P
  • Packing: Bundled/In Bulk, Plastic Caps Plugged, Waterproof Paper Wrapped
  • Usage: For Low Pressure Fluid Transmission, Machinery Manufacturing
  • Description

    Specification

    Standard

    Painting & Coating

    Packing & Loading

    (1) welded pipe from steel plate welding into the round pipe, divided into high frequency resistance welded pipe (ERW welded pipe), straight seam arc welding pipe (LSAW), spiral welded pipe.Electrical engineering with "SC", can be used as water gas pipe can also be used as threading pipe, relatively thick.

    (2)  Pipeline pipe, also known as wire pipe, is relatively thin, denoted by "T", and can only be used for threading.ERW steel pipeERW steel pipe

    (3)  ERW tube is "high frequency resistance welding steel tube", and the common welding process is different, the weld line is from the base material of the steel belt body melted, the mechanical strength is better than the general welding.ERW stands for resistance welding, resistance welding has the characteristics of high production efficiency, low cost, material saving and easy automation, so it is widely used in aviation, aerospace, energy, electronics, automotive, light industry and other industrial sectors, is one of the important welding processes.

    Production Process for ERW steel pipe:

    Uncoiling --- 2. Leveling --- 3. End cutting --- 4. End shearing welding --- 5. Supercoil accumulator --- 6. Edge cutting --- 7. Ultrasonic detection --- 8. Forming --- 9. Electric induction welding --- 10. Ultrasonic detection for weld seam --- 11. Medium frequency heat treatment --- 12. Air cooling --- 13. Water cooling --- 14. Sizing --- 15. Flying cutting --- 16. Flush-out --- 17. Cropping --- 18. Flattening testing --- 19. Straightening --- 20. End facing and bevelling --- 21. Hydrodynamic testing --- 22. Ultrasonic detection for weld seam --- 23. Ultrasonic detection for pipe end --- 24. Visual and dimensions inspection --- 25.Weighting and measuring --- 26. Marking --- 27. Coating --- 28. Pipe-end protection --- 29. Bending --- 30. Shipping

    ERW--01


  • Previous:
  • Next:

  • Dimensions, Specifications, Sizes of ERW Steel Pipe

    OD

    WT

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    Inch

    mm

    0.157

    4

    0.173

    4.4

    0.205

    5.2

    0.22

    5.6

    0.25

    6.4

    0.28

    7.1

    0.312

    7.9

    0.344

    8.7

    0.375

    9.5

    0.406

    10.3

    0.5

    12.7

    0.562

    14.3

    8 5/8

    219.1

























     10 3/4

    273.1

























     12 3/4

    323.9

























    14

    355.6

























    16

    406

























    18

    457

























    20

    508

























    10022

    559

























    241

    610























    ERW Steel Pipe-01 ERW Steel Pipe-02



    Tolerances of Outside Diameter – ERW Steel Pipe

    ERW Steel Pipe-03

    Tolerances of Wall Thickness – ERW Steel Pipe

    ERW Steel Pipe-04

    Lightly oiled, Hot dip galvanized, Electro galvanized, Black, Bare, Varnish coating/Anti rust oil, Protective Coatings

    ERW Steel Pipe-05 ERW Steel Pipe-06
